Parameter Endress+Hauser
Matrix (CW II)
Endress+Hauser-Parameter
error code
last error code
Up Down features
Up Down control
Up Down param
Bus address
Device SW No.
set unit to bus
input value
Select Main value
PA profile revision
Endress+Hauser spezifischer Level Transducer Block
Parameter Endress+Hauser
Matrix (CW II)
Standard Parameter
Block data
Static revision
Device tag
Strategy
Alert key
Target mode
Mode
Alarm summary
Endress+Hauser Parameter
Measured value V0H0
Gap
Tank properties V0H2
Application parameter V0H3
Process properties V0H4
Empty calibration V0H5
Full calibration V0H6
Tube diameter V0H7
Gap
Output on alarm V1H0
Gap
Outp. echo loss V1H2
Ramp %span/min V1H3
Delay time V1H4
Slot Index Size Type
[bytes]
0 54 2 UNSIGNED16
0 55 2 UNSIGNED16
0 56 1 OSTRING
0 57 1 UNSIGNED8
0 58 20 OSTRING
0 59 1 UNSIGNED8
0 60 2 UNSIGNED16
0 61 1 UNSIGNED8
0 62 6 FLOAT+U8+U8
0 63 1 UNSIGNED8
0 64 16 OSTRING
Slot Index Size Type
[bytes]
1 130 20 DS-32*
1 131 2 UNSIGNED16 x
1 132 32 OSTRING
1 133 2 UNSIGNED16 x
1 134 1 UNSIGNED8
1 135 1 UNSIGNED8
1 136 3 DS-37*
1 137 8 DS-42*
1 138 4 FLOAT
139
1 140 1 UNSIGNED8
1 141 1 UNSIGNED8
1 142 1 UNSIGNED8
1 143 4 FLOAT
1 144 4 FLOAT
1 145 4 FLOAT
146 - 147
1 148 1 UNSIGNED8
149
1 150 1 UNSIGNED8
1 151 4 FLOAT
1 152 2 UNSIGNED16 x
Bedienung
Read Write Storage
Class
X dynamic
X X dynamic
X constant
X dynamic
X X dynamic
X dynamic
X dynamic
X X static
X dynamic
X X dynamic
X constant
Read Write Storage
Class
x constant
non-vol.
x x static
x static
x x static
x x static
x dyna-
mic/
non-
vol./
static
x dynamic
x dynamic
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x static
