Fitting And Removing; Attachments - Parkside Performance PHDP 180 A1 Originalbetriebsanleitung

Spot jet
Flat spray (30°)
Foam nozzle for cleaning agent
Turbo dirt miller (22)
The rotating water jet is suitable for
working with low water consumpti-
on.
Surface cleaner (24)
Notes
• Only use the surface cleaner on solid
surfaces.
• Never raise the surface cleaner while
the pressure jet is active.
Properties
Splash-free high-pressure cleaning of
floor and wall surfaces
• High degree of cleaning through rota-
ting nozzles
• Pressure regulator
Control elements
• Pressure regulator (25)
Higher pressure, spray arms
rotate faster
Low pressure, spray arms rotate
slower

Fitting and removing

attachments

Fitting the nozzle
1. Fit the lance (4) on the pistol grip (1)
by inserting and turning it (Bayonet
locking device).
2. Turn and hold the quick connector ring.
3. Fit the attachment on the lance (4).
4. Release the quick connector ring.
The attachment clicks into place.
Removing the nozzle
1. Turn and hold the quick connector ring.
2. Pull the attachment from the lance (4).
3. Release the quick connector ring.
4. Remove the lance (4) from the pistol
grip (1) by turning and pulling it (Bayo-
net locking device).
Mounting the surface cleaner
(24)
1. Remove the lance (4) from the pistol
grip (1) by turning and pulling it (Bayo-
net locking device).
2. Fit the extension tube (8) on the pivota-
ble connection (26) of the surface clea-
ner by inserting and turning it (Bayonet
locking device).
Mounting the extension tube is not re-
quired.
3. Fit the extension tube (the surface
cleaner connection) to the pistol grip
(1) by inserting and turning it (Bayonet
locking device).
Removing the surface cleaner
(24)
1. Remove the extension tube (8) (the sur-
face cleaner connection (26)) from the
pistol grip (1) by turning and pulling it
(Bayonet locking device).
2. Remove the extension tube from the sur-
face cleaner connection (26) by turning
and pulling it (Bayonet locking device).
