15.3.4 <SORTER>
Adresse
Bit
Beschreibung
P001
0
inlet feed motor phase A signal
1
inlet feed motor phase B signal
2
inlet feed motor phase A* signal
3
inlet feed motor phase B* signal
4
escape feed motor phase A signal
5
escape feed motor phase B signal
6
escape feed motor phase A* signal
7
escape feed motor phase B* signal
P002
0
punch feed motor phase A signal
1
punch feed motor phase B signal
2
punch feed motor phase A* signal
3
punch feed motor phase B* signal
4
tray motor CLK signal
5
swing locking motor current switchover I0
6
swing locking motor phase A signal
7
swing locking motor phase B signal
P003
0
TxD for external source
1
TxD for write
2
RxD for external
3
RxD for write
4
punch connection detection
5
OUT for punch communication
6-7
nicht verwendet
P004
0
escape feed motor CLK (IRQ0*)
1
nicht verwendet
2
saddle connection detection
3
upper tray FG (IRQ3*)
4
swing lock HP sensor
5
nicht verwendet
6
front cover open/closed sensor
7
nicht verwendet
P005
0
TxD for punch communication
1
RxD punch for punch communication
2
IN for punch communication (IRQ2*)
3-7
nicht verwendet
COPIER>I/O>SORTER
Bemerkung
-
-
-
-
-
-
-
-
-
-
-
-
-
0: Ein
-
-
-
-
-
-
0: Angeschlossen
0: Ein
-
-
-
0: Angeschlossen
-
1: HP
-
0: Offen
-
-
-
0: Ein
-
429
