Tab. 2 :
Classification key
Information

Fire rated mortice lock

The classification key for this lock is:
3 S 9 1 0
Tab. 2 explains the classification key.
Fire rated Meaning according to DIN EN 12209:2003:
mortice lock
3 for use by the public, where there is little incentive to take
care and there is a high likelihood of misuse, such as in doors
in public buildings
S 200,000
9 Door mass up to 300 kg, maximum 15 N closing force
1 Suitable for use on fire and smoke protection doors, subject
to the satisfactory evaluation of the lock's contribution to the
fire resistance of certain fire and smoke protection doors.
0 No security requirement
C High corrosion resistance,
no temperature requirement
2 Low protective effect and no drilling resistance
H Mortice lock for use in a swing door
A Cylinder lock for manual locking
2 Lock for actuation of a door handle without holding spring
0 No requirement for key identification
C 2 H A 2 0
1 test cycles with a latch load of 50 N
