3
Achtung: Feststellschraube (Innensechskant,SW5) zur
Null lageneinstellung erst nach vollständiger Montage
der Dusche anziehen. Nach ca. 15 Minuten die
Feststellschraube noch einmal auf das max. Drehmoment
von 20N·m nachziehen.
Im dritten Schritt, Nulllage feststellen.
<20 N·m
Drehrichtung rechts zur Feststellung der Nulllage
rotate clockwise to secure the closed position
Attention: Do not tighten the locking screw (hexagon
socket, 5mm) for setting the closed position until the
shower has been completely installed.
After approx. 15 minutes, tighten the locking screw again
to the max. torque of 20N·m.
In the third step, secure the closed position.
9
