Electrical data
RS232 / RS485 common
Transmit buffer size
Receive buffer size
Total buffer size
Data transfer rate
Bus data protocol
Data bits
Stop bits
Data parity
Data packet size
Electrical isolation
RS485
Physical signal
Cable impedance
Cable length
Voltage level, referred to separated GND:
Receive
Transmit, unloaded
Ω
Transmit, 50 load
Ω
Transmit, 18 load
Duplex
RS232
Physical signal
Cable length
Voltage level, referred to separated GND:
Receive
Transmit
Duplex
EMC
EN 61131-2 Product standard
EN 61000-4-2 ESD
EN 61000-4-3 RF-Field & GSM
EN 61000-4-4 Burst
EN 61000-4-5 Surge
EN 61000-4-6 HF-asymmetric
EN 61000-4-8 Magnetic field 50 Hz
EN 55011 Emission
222
Cube67 und Cube67+ Technische Daten
512 ... 3 584 Byte FIFO
512 ... 3 584 Byte FIFO
4 096 Byte
150 to 230 400 Baud
Polling, request
5 ... 8 Bit
1, 1.5, 2 Bit
None, Even, Odd, Mark, Space
3 ... 125 Byte
Galvanically, seperated GND
Differential voltage
120 Ω
Max. 1 200 m (shielded)
-60V ... -0.2V
+60V... +0.2V
> +4.1V logic 0
< -4.1V logic 1
> +1.8V logic 0
< -1.8V logic 1
> +1.1V logic 0
< -1.1V logic 1
Half duplex
Single ended
Max. 15 m (shielded)
-3V ... -31V logic 1
+3V... +31V logic 0
< -13.5V logic 1
> +13.5V logic 0
Full duplex
Contact ± 4 kV, air ± 8 kV
10 V/m
± 1 kV
Asym./symm. ± 500 V (DC input)
Asym. ± 1 kV (Signal connections)
10 V
30 A/m
QP 30 dBµV/m (30 - 230 MHz)
QP 37 dBµV/m (230 - 1000 MHz) (class B)
