2.46.2 Mechanische Daten
Mechanical data
Ambient conditions
Operating temperature
Storage temperature
Enclosure type according to EN 60529
Mechanical ambient conditions
Oscillation according to EN 60068 Part 2-6
Shock according to EN 60068 Part 2-27
Connection possibilities
Internal system connection IN
Internal system connection OUT
Sensor / Actuator
RS485
RS232
Miscellaneous
Dimensions (LxWxH) in mm
Mounting dimension in mm
Weight
220
Cube67 und Cube67+ Technische Daten
0°C ... +55°C
-25°C ... +70°C
IP 67
10 – 58 Hz; const. amplitude 0.35 mm
58 – 150 Hz; const. acceleration 15 g
Amplitude 50 g, 11 ms duration
M12 male plug connector 6-pin
M12 female plug connector 6-pin
2x M12 female connector 5-pin
M12 female connector 5-pin (Reverse-Key coding)
M12 female connector 5-pin (Reverse-Key coding)
151 x 30 x 34,5 mm
75 ± 0.5 mm
Approx. 170 g
