COLLEGAMENTO BARRIERA IN MASTER/SLAVE VIA BUS

MASTER/SLAVE BARRIER CONNECTION VIA BUS
M
MASTER
10 11 12 13 14 15 16 17 18
SLAVE
10 11 12 13 14 15 16 17 18
S
COM
ORO
AP
CH
PP
PED
COM
ANT
COM
FT
COS
COM
ST
19 20
ENC2 LED LIGHT
COM
ORO
AP
CH
PP
PED
COM
ANT
COM
FT
COS
COM
ST
19 20
ENC2 LED LIGHT
Orologio / Timer
Apertura / Opening
Chiusura / Closing
Passo passo / Step by step
Apertura parziale / Partial opening
RG58 max 10 m
Costa di sicurezza MASTER / MASTER Safety edge
STOP (MASTER+SLAVE)
TX
1 2 3
+ -
Costa di sicurezza SLAVE / SLAVE Safety edg
STOP (SLAVE)
20
Antenna
RX
1 2 3 4 5
+ -
23
