Establishing A Connection Via Lan; Establishing A Connection Via Wlan - Fronius Ohmpilot Bedienungsanleitung

4
Establishing a As standard, the Ohmpilot obtains its IP address automatically from the DHCP server,
connection via meaning that no settings are generally necessary.
LAN
The inverter automatically searches for the Ohmpilot, and the search process may take
up to 5 minutes. If the red LED is not lit and the green LED is flashing, the Ohmpilot is
working correctly.
A static IP address can be assigned to the Ohmpilot via the web interface.
1
NOTE!
Access the Ohmpilot via the network.
In networks with a DNS suffix, the Ohmpilot can be accessed at http://ohmpilotL.<DNS-
Suffix>, e.g. http://ohmpilotL.fronius.com
To set the IP address manually, the "Static" option must be selected. Then enter the desi-
red IP address.
The Ohmpilot can then be reached at http://ohmpilotL.local or at the fixed IP address
assigned.
Establishing a There are two options for connecting the Ohmpilot to an existing WLAN network:
connection via
WLAN Connecting via WPS (WiFi Protected Setup)
1
Implement the settings.
Open website http://ohmpilotL.local
Alternatively, the IP address assigned by the DHCP server can also be read out.
Almost every router displays its connected devices (clients) on its web interface.
Apps such as Fing can help you find the automatically assigned IP address. Alterna-
tively, the Ohmpilot can also be searched on the network using the Fronius
Solar.web app.
Press the button on the Ohmpilot 1x.
The blue LED flashes (once) as long as WPS is active.
101
