4.5 PIECES CONTAINED IN THE PACKAGE

ASSEMBLY on STAND
PR-5BL
Drain hose set
*Cart set
-
Supply lid
-
Hose band
3
Suction hose set with filter
1
Dip tube with filter
-
**Gravity hopper set
-
*CART SET
AXLE 1
"U" BOLT _ HEX. NUT 2 + 4
SNAP PIN 4
4
WASHERS
2
SOLID TIRES
HANDLE 1
HEX. NUT (M8) 1
BOLT WITH HEX. HOLE (M8) 1
HEX. NUT (M6) 1
BOLT WITH HEX. HOLE (M6) 1
5. PRODUCT IDENTIFICATION
5.1 PLATE DATA
The manufacturer's identification plate is applied on the diaphragm pump (see picture below).
It must not be removed at all, even if the equipment is resold. For any communication with the manufacturer always mention
the serial number written on the plate itself.
5.2 COMPLIANCE TO THE STANDARD
All the units are conceived in compliance with the applicable Essential Safety Requirements of the Machinery Directive
2006/42/EC. The units are also designed and manufactured in compliance with the Essential Safety Requirements (ESR) of
Annex II of Directive "ATEX" 2014/34/EU and they comply with the following classification:
• Equipment group : II
• Category: Gas 2G (Suitable for use in zones 1 and 2)
• Max. surface temperature: temperature class T6
• X marking : Any static electricity discharge from the pump is to be diverted to the ground through the
grounding wire which is included in this product.
6
DIAPHRAGM PUMPS
on CART ALL MODEL on TANK MOUNT on WALL MOUNT
1
1
1 -
- 1
3 -
1 -
- 1
1 -
**HOPPER SET
HOPPER 1
"U" HOSE 1
DPS-120 C - DPS-90 G

6. TECHNICAL SPECIFICATIONS

Pump Unit
-
-
3
1
DDP-120B
PUMP TYPE
-
-
PUMP VERSION
Paint Passages Aluminum
Air Working
Pressure Range
Max. Fluid
Working Pressure
Air Inlet
Fluid Outlet
Fluid Inlet
Paint Delivery
at 30 cyc/min
Paint Delivery
at 200 cyc/min
Paint viscosity
Working
Temperature
Compressor
(required power)
Noise Level
PERFORMANCE CURVE
DIAPHRAGM PUMPS
DDP-120BN DDP-120B-WB DDP-90F
DPS-120C.TE
Stainless Anodized
Aluminum
Steel Aluminum
1.5~7 bar
22~100 psi
7 bar (100 psi)
G 1/4"
G 3/8"
G 1/2"
4.5 lt./min
30lt./min
85sec/Ford#4
5~40°C
0.4~1.5 kW
70 dB(A)
* 0.3/0.5/0.7 MPa in graph shows air pressure * 0.3/0.5/0.7 MPa in graph shows air pressure
* Test by turpentine * Test by turpentine
EN
DDP-90FN DDP-90F-WB
DPS-90G.TE
Stainless Anodized
Steel Aluminum
1.5 lt./min
10lt./min
0.4~0.75 kW
68 dB(A)
