9.3 Bevel cuts (Fig. 14)
Always use the parallel stop (7) when cutting bevels.
Fix the saw table in the required angle position
(see 8.4).
Move the workpiece along the parallel stop (7).
In this connection see also section 9.1 or 9.2,
depending on the width of the workpiece.
9.4 Cutting 45° mitres in small workpieces
(Fig. 13)
Always use the parallel stop (7) plus the mitre stop
(14) or the cross stop (8) to cut 45° mitres in small
workpieces.
Mount the angle stop (14) on the parallel stop
(7).
Adjust the parallel stop (7) to the required length
of the workpiece and clamp securely.
Insert the workpiece in the angle stop (14).
Switch on the saw and push the angle stop (14)
together with the piece of wood along the
parallel stop (17) into the blade (4).
Switch off the saw when the cut is completed.
9.5 Cutting with the cross stop (Fig. 15)
Insert the cross stop (8) in the runner slot (35) of
the saw table (1).
Slacken the knurled screw (9) and set the
angle by turning the guide bracket.
Re-tighten the knurled screw (9).
Slide the cross stop forward as far as the blade.
Slacken the thumb screw (37) and slide the stop
rail forward until a distance of around 2 cm is left
between the blade and the stop rail.
Re-tighten the thumb screw (37).
Pull back the cross stop again and place a piece
of wood against the stop rail (18).
Switch on the saw.
Press the piece of wood firmly against the stop
rail (18) and slide the cross stop toward the
blade to make the cut.
Switch off the saw when you have completed the
cut.
18
All manuals and user guides at all-guides.com

10. Maintenance

11. Ordering replacement parts

Please quote the following data when ordering
replacement parts:
Remove dust and dirt regularly from the
machine. Cleaning is best done with
compressed air or a rag.
Never use caustic agents to clean plastic parts.
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
Item No.
2
3
4
6
7+12+18+20
8+9
11
14
15
16
19
Art. No.
434070001
434031059
45.020.39
434070002
434070003
434070004
434070005
434060033
434070006
434070007
434070008
