8.0 Using the saw

8.1 On/Off switch (Fig. 1)
The saw can be switched on by pressing the
green pushbutton Å.
The red pushbutton Ä has to be pressed to
switch off the saw.
8.2 Parallel stop
8.2.1 Stop height (Fig. 7/8)
The parallel stop (7) supplied with the bench-
type circular saw has two different guide faces.
For thick material you must use the stop rail (18)
as shown in Fig. 7, for thin material you must use
the stop rail as shown in Fig. 8.
To change the height of the stop, slacken the two
screws (20) and pull the stop rail (18) off the
carrier rail (26).
Turn the stop rail (18) 90° to the left or the right,
depending on the required height of the stop,
and plug in back on the carrier rail (26).
Tighten the screws (20).
8.2.2. Stop length (Fig. 7/8)
To prevent the workpiece becoming jammed,
always slide the stop rail (18) to the front edge of
the table (1) and fix it in place with the two
screws (20) (see 8.2.1).
8.2.3 Cutting width (Fig. 8)
The parallel stop (7) has to be used when
making longitudinal cuts in wooden workpieces.
Slide the parallel stop (7) to the right or left side
of the saw table (1).
The parallel stop (7) can be set to the required
dimension with the help of the scale (b) engraved
on the saw table (1).
Tighten the two thumb screws (12) in order to fix
the parallel stop (7).
All manuals and user guides at all-guides.com
8.3 Adjusting the cutting depth (Fig. 8)
8.4 Adjusting the angle (Fig. 9/10)
9. Sawing operations
After each new adjustment it is advisable to
carry out a trial cut in order to check the set
dimensions.
After switching on the saw, wait for the blade to
reach its maximum speed of rotation before
commencing with the cut.
Secure long workpieces against falling off at the
end of the cut (e.g. with a roller stand etc.)
Take extra care when starting the cut!
9.1 Cutting narrow workpieces
9.2 Cutting extremely narrow workpieces
To change the cutting depth of the blade (4) you
have to turn the hand crank (15) anti-clockwise
to increase the cutting depth or clockwise to
decrease the cutting depth.
The cutting depth can be read of the scale (30).
You can use the nut (29) to fix the set cutting
depth.
Slacken the locking handles (16).
You can adjust the saw blade (4) to the required
angle (see the scale (a)) by turning the hand
crank (17).
Retighten the locating handles (16).
(width less than 120 mm) (Fig. 11)
Adjust the parallel stop (7) to the width of
workpiece you require.
Feed in the workpiece with two hands. Always
use the push stick (3) in the area of the saw
blade (4).
(A push stick is supplied with the saw!)
Always push the workpiece through to the end of
the splitter (5).
Caution! With short workpieces, use the push
stick from the beginning.
(width less than 30 mm) (Fig. 12)
Adjust the parallel stop (7) to the width of
workpiece you require.
Use the push block (c) to press the workpiece
against the parallel stop (18) and push the
workpiece with the push stick (3) through to the
end of the splitter (5).
There is no push block supplied with the
saw!
(Available from your specialist dealer)
