6.6 Fitting/replacing the blade (Fig. 7)
•
Caution! Pull out the power plug.
•
Wear work gloves when changing the saw
blade!
•
Remove the table insert by undoing the coun-
tersunk head screw (see 6.4).
•
Hold the saw blade flange (j) with the tool for
changing the saw blade (33).
•
Undo the nut using the ring wrench (37).
•
Important! Turn the nut in the direction of
rotation of the saw blade.
•
Take off the outer flange and pull the old saw
blade off the inner flange by dropping the bla-
de at an angle.
•
Clean the blade flange thoroughly before fit-
ting the new blade.
•
Mount and fasten the new saw blade in rever-
se order.
•
Important! Note the running direction. The
cutting angle of the teeth must point in run-
ning direction, i.e. forwards (see the arrow on
the blade guard).
•
Refit and set the splitter (5) and the saw gu-
ard (2) (see 6.3., 6.5.)
•
Check to make sure that all safety devices
are properly mounted and in good working
condition before you begin working with the
saw again.

7. Using the saw

Switch on an extraction system prior to star-
ting with the work.
7.1 ON/OFF switch (Fig. 1)
•
To turn the saw on, press the green button
"I". Wait for the blade to reach its maximum
speed of rotation before commencing with the
cut.
•
To turn the machine off again, press the red
button "0".
•
In case of an emergency, press the red cap.
This also switches the machine off.
7.2 Cutting depth (Fig. 1)
Turn the hand crank (8) to set the blade (4) to the
required cutting depth.
Turn anti-clockwise:
larger cutting depth
Turn clockwise:
smaller cutting depth
Anl_TC_TS_2031_U_SPK1.indb 29 Anl_TC_TS_2031_U_SPK1.indb 29
GB
7.3. Parallel stop
7.3.1 Stop height (Fig. 11-14)
•
Use the holder (24) together with the parallel
stop rail (23) as a parallel stop.
•
For thick material you must use the stop rail
(23) as shown in Fig. 12, for thin material you
must use the stop rail as shown in Fig.13.
•
To change over the stop rail (23) to the lo-
wer guide face you have to slacken the two
knurled screws (26) in order to disconnect the
stop rail (23) from the holder (24).
•
Remove the two knurled screws (26) through
the one slot (27) in the stop rail (23) and in-
sert in the other slot (25).
•
Remount the stop rail (23) on the holder (24).
•
The procedure for changing over to the high
guide face is similar.
7.3.2 Cutting width (Fig. 11, 14)
•
The parallel stop (7) has to be used when
making longitudinal cuts in wooden workpi-
eces.
•
The parallel stop (7) can be mounted on the
right-hand side of the saw table (1).
•
The parallel stop (7) has to be mounted in the
guide rail (28) of the saw table (1).
•
The parallel stop (7) can be set to the requi-
red dimension with the help of the scale (22)
on the table.
•
You can clamp the parallel stop in the requi-
red position by pressing the eccentric lever
(12).
•
Be aware that the scale (22) on the table
does not account for the high and horizontal
position of the parallel stop at the same time
– carry out a trial cut if necessary in order to
check the set dimension.
7.3.3 Setting the stop length (Fig. 11-14)
•
The stop rail (23) can be moved in longitudi-
nal direction in order to prevent the workpiece
from becoming jammed.
•
Rule of thumb: The rear end of the stop co-
mes up against an imaginary line that begins
roughly at the center of the blade and runs at
an angle of 45° to the rear.
•
Set the required cutting width
- Slacken the knurled screws (26) and push
the stop rail (23) forward until it touches the
imaginary 45° line.
- Retighten the knurled screws (26).
