This document applies to the microScan3 safety laser scanner and the associated sys‐
tem plug with the following part numbers:
Safety laser scanner
•
1082015
• 1082016
•
1091037
• 1091038
•
1092538
• 1092539
• 1092542
• 1092543
• 1092720
• 1092721
• 1094455
• 1094457
• 1094461
•
1094463
• 1094465
•
1100404
• 1100406
•
1100408
• 1102625
• 1102626
• 1102627
• 1102628
• 1102629
• 1102630
•
1103032
• 1103033
• 1103950
• 1108226
• 1108228
•
1108230
• 1108232
•
1108234
Symbols and document conventions
A, B References to the figures at the end of this document are indi‐
cated by a black background.
DANGER
Hazard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
Please observe the safety notes provided.
