Hand-Held Pressure Indicator
CPH6200-S1 / CPH6200-S2
1. On/Off key
2. Set/Menu: Enter Configuration Menu (press for 2 sec)
3. Tare:
4. Store/Quit: Activate hold function or logger function (see Section "3.
5. Min/Max:
Max-Function: Pressing ´Max´ shows the maximum measured value record-
Min-Function: Pressing ´Min´ shows the minimum measured value record-
Hold-Function: By pressing ´Store/Quit´ the instantaneous measured value
Logger-Functions: Activated by the ´Store/Quit´ key, only if the logger has
Tare-Functions: By pressing ´Tare´, the display will be set to 0. All measure-
Activating/deactivating tare clears the max- and min-memories.
Zero-Point Adjust: (for gauge pressure sensors only) If there is no pressure
A zero-point adjustment can only be carried out if the difference
between the value on display is less than 500 digits!
If a zero-point adjustment has been made, this will be signalled by the
message "nuLL-Corr" being displayed briefly as the device is turned on.
Differential pressure: Pressing ´Set/Menu´ shows the difference between
WIKA Operating Instructions Hand-Held Pressure Indicator
Activate tare function, zero point adjustment
Operation of logger".)
Display the respective min-/max-memory value in lower
display
ed. Pressing it again hides it. To clear the max-memory press
the ´Max´ key for > 2 seconds.
ed. Pressing it again hides it. To clear the min-memory press
the ´Min´ key for > 2 seconds.
will be shown in the lower display. Pressing it again hides it.
(Only when the main menu item logger = 'off' is selected).
been selected via the main menu (see Section "3. Operation
of logger").
ments from then on will be displayed relative to the set tare
value. When the tare function is activated, the arrow ´Tare´
appears in the display. To deactivate the tare function press
´Tare´ for > 2 seconds.
applied to the pressure ports the device will display 0. If
there is a permanent offset (and the device is being used
under steady conditions), a permanent zero point adjust-
ment can be carried out. To carry out the adjustment, press
´Tare´ for approx. 5 seconds. (Please note: A zeropoint
adjustment can only be made if the difference between the
display value and the factory calibration value is less than 2
%! E.g. for a measuring range of 0 ... 25 bar, => zeropoint
adjustment up to 0.5 bar possible). To revert to the factory
calibration, press ´Tare´ for approx. 15 seconds.
the measured values of Channel 1 and Channel 2
(DIF=CH1-CH2) in the lower display. Pressing it again will
hide it (only with the 2-channel version and when 2 sensors
are connected).
