1.3 Ports and Connectors

1.3.1 PS/2 Mouse and PS/2 Keyboard Ports
PS/2 Mouse
PS/2 Keyboard
Make sure to turn off your
computer prior to connecting
or disconnecting a mouse or
keyboard. Failure to do so
may damage the mainboard.
1.3.2 RJ45 Fast-Ethernet Port (PM10-EL only)
RJ45 LAN
