1
Quick Setup Guide
1.3.3 Universal Serial Bus Ports
USB 2
USB 1
Additional USB Ports (USB 3 and USB 4)
Pin Function
VCC
1
UP5-
2
3 UP5+
4 Ground
5 Key
The Wake-On-USB Keyboard/Mouse function, when enabled, allows a USB
keyboard/Mouse to wake up a system that is in the S3 (STR - Suspend
To RAM) state.
10
manuals search engine
J2
11 15
1 5
Pin Function Pin Function
6 11
VCC Ground
7 12
UP6- Ground
8 13
UP6+ UP5+
9 14
Ground UP5-
10 15
N. C. VCC
USB 3/4 (J5)
15
11
1 5
