Quick Setup Guide

1.3.14 Power Connectors

1 3
4
2
+12V power
(ATXP1)
ATX Main Power
1 3.3V
2 3.3V
3 Ground
4 +5V
5 Ground
6 +5V
7 Ground
8 PW-OK
9 5VSB
1 0 +12V
The systme board requires a minimum of 300W electric current.
16
manuals search engine
10 20
1 11
ATX power
1 3
(J19)
2 4
+12V Power
1 Ground
1 1 3.3V
2 Ground
1 2 -12V
3 +12V
1 3 Ground
4 +12V
1 4 PS-ON
1 5 Ground
1 6 Ground
1 7 Ground
1 8 -5V
1 9 +5V
2 0 +5V
20
10
1 11
