1.4.7 Power Connectors

1 3
2 4
+12V power
(ATXP1)
The systme board requires a minimum of 300W electric current.
ATX Main Power
1
2
3
4
5
6
7
8
9
1 0 +12V
66500237 1.pmd
manuals search engine
11 1
20 10
1 3
2 4
20
ATX power
(J17)
+12V Power
1 Ground
3.3V
1 1 3.3V
2 Ground
3.3V 1 2 -12V
3 +12V
Ground
1 3 Ground
4 +12V
+5V
1 4 PS-ON
Ground 1 5 Ground
+5V
1 6 Ground
Ground
1 7 Ground
PW-OK 1 8 -5V
5VSB
1 9 +5V
2 0 +5V
17
1
