Pin assignment

A
8025886/2020-08-31 | SICK
Subject to change without notice
Figure 1: Terminals on the power supply plug
Terminal assignment on the power supply plug
Terminal Signal
1 24 V DC
2 –
3 0 V DC
M6 × 8
Function
Supply voltage
Reserved
Supply voltage
