About this document

2

Safety information

3

Mounting the device

6 M O U N T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
All rights reserved. Subject to change without notice.
This document applies to the safety laser scanner and the associated system plug with
the following part numbers:
System
• 1045650
• 1045651
• 1045652
• 1045653
• 1045654
• 1045655
• 1052591
• 1052592
• 1052593
• 1052594
• 1052595
• 1052596
Symbols and document conventions
A, B References to the figures at the end of this document are indi‐
cated by a black background.
DANGER
Hazard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
Please observe the safety notes provided.
b
For more information about how to work with the protective device, refer to the machin‐
ery documentation or the operating instructions for the protective device. You can call
up the EU declaration of conformity and the current operating instructions for the pro‐
tective device by entering the part number in the search field at
number: see the type label entry in the "Ident. no." field).
Mounting the device: A
The device has threaded holes on the rear. They can be used to mount the device
directly if you are able to drill through the mounting surface from behind.
Sensor head
• 2049566
• 2049567
• 2049568
