APCI-/CPCI-1710
5)

i_APCI1710_GetPWMInitialisation (...)

Syntax:
<Return Wert> = i_APCI1710_GetPWMInitialisation
Parameter:
- Eingabe:
BYTE b_BoardHandle
BYTE b_ModulNbr
BYTE b_PWM
- Ausgabe:
PBYTE pb_TimingUnit
PULONG pul_LowTiming
PULONG pul_HighTiming
PBYTE pb_StartLevel
PBYTE pb_StopMode
PBYTE pb_StopLevel
(BYTE b_BoardHandle,
BYTE b_ModulNbr,
BYTE b_PWM,
PBYTE pb_TimingUnit,
PULONG pul_LowTiming,
PULONG pul_HighTiming,
PBYTE pb_StartLevel,
PBYTE pb_StopMode,
PBYTE pb_StopLevel,
PBYTE pb_ExternGate,
PBYTE pb_InterruptEnable,
PBYTE pb_Enable)
Handle der Karte APCI-/CPCI_1710
Nummer des zu konfigurierenden Moduls (0
bis 3)
Ausgewählter PWM Generator (0 oder 1)
Base timing Unit (0 to 4)
0: ns
1: µs
2: ms
3: s
4: mn
Low base timing value.
See base timing value description table
High base timing value.
See base timing value description table
Start period level selection
0: The period starts with a low level
1: The period starts with a high level
Stop mode selection
0: The PWM is stopped directly after the
function "i_APCI1710_DisablePWM" and
stops the current period
1: After the function
"i_APCI1710_DisablePWM" the PWM is
stopped at the end of the current period
Stop PWM level selection
0: The output signal keeps the level after the
function "i_APCI1710_DisablePWM"
1: The output signal is set to low after the
function "i_APCI1710_DisablePWM"
2: The output signal is set to high after the
function "i_APCI1710_DisablePWM"
Standardsoftware
27
