LITHIUM BATTERY(LiPo/LiFe/LiIon/LiHV)PROGRAM A
Start
Enter
Number Battery
Charging
of
voltage
time
cells
Charging
current

CHARGING OF LITHIUM BATTERY

This charging mode is for charging LiPo/LiFe/LiIon/LiHV battery in
normal mode.
Note: We recommend charging lithium batteries with a balance lead
in the balance mode only.
-
+
DEC. INC.
Batt type Start
Stop Enter
This screen displays the number of cells you
set up and the processor detects.
R=Number of cells detected by charger.
S=Number of cells set by you at the previous
screen.
If both numbers are identical you can start
charging process. If not, press BATT TYPE/
STOP button to go back to previous screen
to recheck the number of cells of the battery
pack before going ahead.
This screen shows the real-time status during
charge process. Press BATT TYPE/STOP
button once to stop the charge process.
Charged
capacity
The left side of the first line shows the type
of battery you choose. The value on the left
of the second line of the charger is current
-
+
the user sets. After setting the current and
DEC. INC.
voltage, press the START/ENTER button for
>3 seconds
more than 3 seconds to start the process.
This displays the number of cells you set up
and the processor detects.
R=Number of cells detected by charger.
S=Number of cells set by you at the previous
screen.
14
