• Store grinding wheels in such a way that they are
not subject to mechanical loads or damaging en-
vironmental influences.
• Do not use damaged or unshaped wheels.
• The adjustment of the spark guard shall be made
frequently, so as to compensate the wear of the
wheel, keeping the distance between the guard and
the wheel as small as possible, and no greater than
2 mm.
• The adjustment of the work rest shall be made fre-
quently, so as to compensate the wear of the wheel,
keeping the distance between the work rest and the
wheel as small as possible, and no greater than 2
mm.
• Use wheels that have a bore exactly equal to the
arbor of the grinder. Do not attempt to machine an
undersized wheel to fit an arbor.
• Do not overtighten wheel nut.
• Do not grind on a cold wheel. The grinding wheel
should be started and run at idle speed for one
minute before applying the work.
• Do not grind on the side of the wheel. Grind on the
face of the wheel only.
• Do not apply coolant directly to a grinding wheel.
Coolant can weaken the bonding strentgh of the
wheel and cause it to fail.
• Sparks are a hazard. Do not grind near gas or
flammable liquids.
• Stand to one side of the wheel when turning on the
power. Dress the wheel on the face only. Dressing
the side of the wheel can cause it to become too
thin for safe use.
• Grinding creates heat. Do not touch the work piece
until you are sure it has cooled down sufficiently.
• Use grinding wheels that are rated for safe use on
the grinder. Do not use a wheel that is rated lower
than the grinder speed.

6. Technical Data

Delivery
Bench Grinder SM150L
Technical Data
Dimensions L x W
380x210x280
x H mm
ø grinding disc
150
max. mm left/right
ø grinding disc
min. mm left/right
110
(after wear and
tear)
ø grinding disc
12,7
bore max. mm
grinding disc
20/20
width mm left/right
Lamp LED with battery (2x)
7
Weight kg
Motor
Motor V/Hz
230-240/50
Input power
400
S2 10 min W
Motor speed 1/min 2850
Subject to technical changes!
18 GB
User's Manual
Load factor:
A load factor of S2 10 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (400 W) for no longer than
10 minutes ON period. If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
64,9 dB(A)
L sound pressure level
pA
3 dB
K uncertainty
pA
L sound power level 76,1 dB(A)
WA
3 dB
K uncertainty
WA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 61029.
Vibration emission value a
h
K uncertainty = 1.5 m/s
2
Warning!
The specifi ed vibration value was established in ac-
cordance with a standardized testing method. It may
change according to how the electric equipment is
used and may exceed the specifi ed value in excep-
tional circumstances.
The specified vibration value can be used to com-
pare the equipment with other electric powertools.
The specified vibration value can be used for initial
assessment of a harmful effect.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect working-
order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.

7. Assembly

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
Pull the power plug before doing any mainte-
nance or assembly work on the equipment.
• The machine must be set up so that it stands firm-
ly, i.e. it must be securely screwed to a work bench
or similar.
≤ 2.5 m/s
2
