1.3.1 PS/2 Mouse and PS/2 Keyboard Ports
Make sure to turn off your computer
prior to connecting or disconnecting a
mouse or keyboard. Failure to do so
may damage the mainboard.
1.3.2 USB Ports and RJ45 Fast-Ethernet Port
RJ45 LAN
USB 2
USB 1
Additional USB Ports
(USB 3 to USB 4)
1 5V_Dul
3 Data-
5 Data+
7 Ground
9 Key
Only PE11-TL system supports RJ45 Fast-Ethernet Port.
66500237 1.pmd
manuals search engine
J11
PS/2 Mouse
PS/2 Keyboard
CN1
2 5V_Dul
4 Data-
6 Data+
8 Ground
1 0 Ground
2
1
USB 3 and USB 4
(J13)
11
1
Quick Setup Guide
2 10
1 9
10 2 10
1
9 9
USB 5 and USB 6
(J24)
11
