6. Systemkon guration

6.7 Connected XPDR System Con guration

The XPDR SYSTEM section contains setup parameters for a connected XPDR system. Please
consult the XPDR system's documentation for details on parameters and recommended
values.
Note that for the VT-01, the system state, software versions, and con guration is not known
to the ACD-57 unless the VT-01 has been set to ALT mode at least once during the runtime
of the ACD-57.
6.7.1 Flight ID
In this menu, a ight ID can be entered. The ight ID must correspond to the aircraft
identi cation speci ed in item 7 of the ICAO ight plan, or, when no ight plan has been
led, the aircraft registration.
To enter a ight ID, please carry out the following steps:
1. Open the menu with a long push on the inner knob pushbutton .
2. Use the inner knob to navigate to XPDR SYSTEM
3. Use the outer knob to select a position/digit and the inner knob to change the
value at this position.
4. Push the inner knob pushbutton to execute your selection.
5. Push the ESC softkey to leave the menu.
42
FLIGHT ID.
