Systemkon guration

6.1 Con guration Operations

6.1.1 Con guration Menu
ACD-57 is con gured in the con guration menu. To enter the con guration menu, push
the inner knob pushbutton for at least 2 seconds (long push). The menu contains several
con guration options and informations about ACD-57 and connected systems.
Please nd a menu diagram in appendix B
6.1.2 Pin Code Protection
This manual contains only a few con gurable parameters. These parameters are always
accessible to the ight crew. The ACD-57 has many more con gurable parameters and
a large con guration menu. Due to safety reasons and regulatory requirements, not all
con guration parameters are readily accessible. Many con guration menu levels require the
entry of a pin code before they can be accessed. Pin codes can be entered in CONFIGURATION
MENU PIN CODE.
For a detailed overview of all con gurable parameters and their recommended values,
please consult the ACD-57 installation manual.

6.2 Device Con guration

In the con guration menu, DEVICE contains information about the ACD-57 device itself.
6.2.1 Info
In the DEVICE menu, INFO contains speci c information about the ACD-57 device such as
hardware and software version information.
6.2.2 Status
In the DEVICE menu, STATUS contains information about the power supply voltage, the
position data source, and the pressure data source.
6.2.3 Illumination Override
In the DEVICE menu, ILLUMIN OVERRIDE the current display and knob illumination level can
be manually set.
Until the next restart of the ACD-57, this setting overrides the current illumination con gu-
34 ACD-57 Pilot's Manual rev. 2.1 2018/07/12
