AIR Avionics AIR Control Display 57 Handbuch Seite 45

air avionics
SAGN
118.275
Figure 6.3.: COM main page with KNOB USE parameter set to VOLUME on the left and to
CHANNEL on the right.
In aircraft with no audio panel or intercom, we recommend to use the default setting (KNOB USE set to
VOLUME). If an audio panel/intercom is used, it may not be required to change COM volume frequently.
In this case, setting the KNOB USE parameter to CHANNEL is recommended for easier channel selection.
To change the knob use con guration, please carry out the following steps:
1. Open the menu with a long push on the inner knob pushbutton .
2. Use the inner knob to navigate to COM CONTROL
3. Use the inner knob to to select a desired option (VOLUME or CHANNEL).
4. Push the inner knob pushbutton to execute your selection.
5. Push the ESC softkey to leave the menu.
ACD-57 Pilot's Manual rev. 2.1 2018/07/12
CHN NRST HIST
WALLDORF INFO
129.970
MALSCH GLD
SAGN VOL NRST HIST
118.275
WALLDORF INFO
129.970
MALSCH GLD
KNOB USE.
6. Systemkon guration
39
