ration that has been entered during device installation. After a restart, the illumination
con guration that has been entered during installation is restored.
To override the illumination con guration, please carry out the following steps:
1. Open the menu with a long push on the inner knob pushbutton .
2. Use the inner knob to navigate to DEVICE
3. Once the illumination override page is entered, the illumination con guration is
shown. Use the inner knob to override the illumination con guration and to enter
a manual value.
4. Push the inner knob pushbutton to execute your selection.
5. Push the ESC softkey to leave the menu.
To reset the override and get back to the illumnation con giuration entered during
installation, push the RESET softkey .
DONE
ILLUMINATION MODE
OVERRIDE
Figure 6.1.: Illumination override page. On the left the automatic illumination con guration
is active, current illumination mode is shown. On the right the override is active.
ACD-57 Pilot's Manual rev. 2.1 2018/07/12
DONE
ILLUMINATION OVERRIDE
AUTO
OVERRIDE
ILLUMIN OVERRIDE
RESET
75
FAST +/- +/-
ACTIVE
6. Systemkon guration
