6. Systemkon guration

6.3 Altimeter Con guration

The ALTIMETER menu section contains speci c con guration parameters for the integrated
altimeter.
6.3.1 Units
Units for altitude and pressure are user con gurable.
Altitude units con gurable to meters or feet
Pressure units con gurable to hectopascals (millibars) or inches of mercury
The default settings are meters and hectopascals. To change the altimeter units con guration,
please carry out the following steps:
1. Open the menu with a long push on the inner knob pushbutton .
2. Use the inner knob to navigate to ALTIMETER
3. Use the inner knob to navigate to a unit category, use the inner knob pushbutton
to enter the menu.
4. Use the inner knob to select the desired unit.
5. Push the inner knob pushbutton to execute your selection.
6. Push the ESC softkey to leave the menu.
36
UNITS.
ACD-57 Pilot's Manual rev. 2.1 2018/07/12
