Virutex PEB200 Gebrauchsanweisung Seite 23

(Figure 3)
A
B
(Figure 4)
(Figure 5)
A
(Figure 6)
• Turn lever A (Fig. 3), remove the plate guide B (Fig. 3) and
B
assemble it as shown in (Fig. 4).
• Check that the handles A and B (Fig. 5) are aligned as shown.
• Save the wooden box and cover for storing and transporting
the gluing machine.
A
6. RECOMMENDATIONS BEFORE FIRST
USING THE PEB250
• The edge of the board to be banded must be at 90º to the
top surface and free of dust. For boards with an inclination of
up to 10º, see section 8.4 Inclined guide plate adjustment.
• The edge must have a good surface to obtain a perfect finish
when banding chip boards with thin edges.
• The pieces and the edges that are going to be glued must
be at a temperature of at least 18°C (64ºF).
• Always apply sufficient force on the edge to obtain a good
banding.
• Check that the quantity of glue that the edge receives is
appropriate by doing a trial run.
• Do a trail run before banding concave or convex curves.
• The glue tank must be closed and dry.
• The glue gives off fumes when at working temperature.
Make sure these are eliminated by keeping the workplace
well ventilated.
• Keep the machine free of dust or shavings. If the machine
is dirty you will obtain bad quality veneers.
• Make sure you have enough fully melted glue in the tank to
finish the job. If glue needs to be added to the tank for this,
B
activate the gluing speed some 5 minutes earlier (see section
9.2 Controlling the gluing speed).
• When you are going to glue the edges, use Virutex special
glue for PEB200/PEB250 (ref. 2599266), which has been spe-
cially developed for this purpose.
• You can also use one of the following glues which have been
approved by Virutex for use in the PEB200/PEB250:
- Rayt type MA-6244
- Kleiberit 743.7
A
- Kleiberit VP9296/57
- Jawat 280.3
- Dorus KS224/2
• Virutex only guarantees that edgebander PEB200/PEB250
will work correctly if one of the recommended glues are used.
• Hold the machine horizontally during and after use.
B
• The glue control knob B, and the glue tank lid A (Fig. 6)
get blocked with glue when the machine cools down. Do not
adjust the knob or lift the lid until the machine is hot again
and the glue has melted.
PEB200-PEB250 / Operating instructions - 23
