Installation Instructions CP 1411
1

Description of the CP 1411

1.1

General Description

Hardware The CP 1411 is a card for IBM-AT compatible PCs or PGs and re-
quires a 16-bit ISA slot for operation.
Requirements
Ethernet The CP 1411 is intended for operation in networks handling communi-
cation using the CSMA/CD medium access technique (Ethernet).
Connections The CP 1411 is connected to the LAN (Local Area Network) using one
of the two female connectors on the front panel of the CP.
LED Display To indicate module activity, the CP 1411 has an LED on its front panel
that lights up when data is received.
1.2

Network Attachments

15-pin sub D The 15-pin sub-D female connector with its slide locking mechanism is
intended both for connection of AUI transceiver cables (AUI Attach-
female connector
ment Unit Interface) as well as ITP cables (ITP - Industrial Twisted
Pair).
Switching between If you use Siemens ITP cables, the module switches over between AUI
and ITP automatically.
AUI and ITP
RJ-45 Female The RJ-45 connector is designed for the attachment of TP cables
Connector (TP - Twisted Pair).
Caution in an In an industrial environment, only the AUI or ITP connectors should be
used due to their superior noise immunity.
Industrial
Environment
Note that it is not possible to use both connectors at the same
time.
