Center the Image on the Disc

The Rimage 2000i provides two ways to center the image on the disc. You can use the Auto Centering method or the Manual
Centering method. The following procedure describes both methods. The Auto Centering method is accurate to within +/- 0.5
mm. You can improve the centering position accuracy with the Manual Centering adjustment to better than +/- 0.2 mm.
Tip: Use the Center Image functionality only if the printed image is not centered on the disc. Image centering is set by the
manufacturer and usually does not need to be recalibrated in the field.
For optimal print quality, use the following procedure to center the image on the disc.
1. Access Printing
2. Press . The printer tray opens.
3. Place a 120 mm white disc (Qty. 1) on the tray.
4. On the Service tab, select Service ToolBox. The Service ToolBox dialog box opens.
5. Select Center Image. The Centering Margins for Disc Color Printer 480i dialog box opens.
6. Follow the onscreen instructions to use either the Auto Centering or the Manual Centering method.
7. When the image is centered, select OK. The Centering Margins for Disc Color Printer 480i dialog box closes.
8. Select OK. The Rimage Service ToolBox dialog box closes.
9. Select OK. The Preferences window closes.
10. Press . The printer tray closes.

Check the Ink Levels

This functionality allows you to check the current levels of ink in the cartridges.
Tip: If you remove the ink cartridges and reinsert them, the system resets to show that the cartridges are full, regardless
of the actual fill status.
1. Access Printing Preferences.
2. On the Service tab, select Service ToolBox. The Service ToolBox dialog box opens.
3. Select Get Ink Level. Ink level information displays in the PrinternStatus field.
4. Select OK. The Rimage Service ToolBox dialog box closes.
5. Select OK. The Preferences window closes.
