not approved by L'Inglesina Baby S.p.A.
WHAT TO DO IF YOU REQUIRE ASSISTANCE
• If you require assistance for your product, immediately
contact the Inglesina Retailer that sold it to you, with the
"Serial Number" relative to said object ready on hand.
• It is the Retailer's duty to contact Inglesina to assess the
best suited intervention case by case and then provide the
subsequent indications.
• The Inglesina Customer Care Service can provide any
information, following written request by filling out the
form provided on the website: inglesina.com - Warranty and
Assistance section.
HINTS FOR CLEANING AND MAINTAINING THE PRODUCT
• This product requires regular maintenance by the user.
• Never force any mechanisms or moving parts; in case of
doubt, check the instruction first.
• Do not store the product if it is still wet and do not leave it
in humid environments since mildew may form.
• Store the product in a dry place.
• Protect the product against weather agents, water, rain
or snow; moreover, continuous and prolonged exposure to
sunlight can cause changes in the colour of many materials.
• Should the product be used on the beach, carefully clean
and dry it afterwards in order to remove sand and salt as they
may cause rusting.
• Clean the plastic and metal parts with a damp cloth or with
LIST OF COMPONENTS
fig. 1
A Hood
B Handrail
C Storage basket
D Rain cover (if available)
"SELF STANDING" SUPPORT
fig. 2 In order to allow the stroller to remain upright on
its own, pull out the support (S1) and place it in its housing.
STROLLER OPENING
fig. 3 To open the stroller, use both levers (P1) and
simultaneously, holding the handle firmly, lift the stroller
until the correct opening click is heard.
Warning: before use, make sure that the stroller is
correctly opened by checking that the red area is no
longer visible from both sides.
Caution: use the levers (P1) exclusively while opening
and closing the stroller. Be careful not to operate them
accidentally during the normal use of the stroller.
REMOVING/ATTACHING THE FRONT WHEEL ASSEMBLY
In case of need, the front wheel assembly (D) can be easily
removed.
fig. 4 To remove it, pull it out from the front support
while holding down the lever (D1).
fig. 5 To reinstall it, simply position it and push it until it
clicks into place.
fig. 6 Caution: make sure that the wheels are properly
attached before use.
REMOVING/ATTACHING THE REAR WHEELS
Should it be necessary, the rear wheels (E) can easily be
removed.
fig. 7 Use a screwdriver (or similar tool, not included) to
a mild detergent; do not use solvents, ammonia or benzine.
• Carefully dry metal parts after any contact with water to
prevent the formation of rust.
• Keep all moving parts clean and, if necessary, lubricate
them with light oil.
• Seat cover and harness are surface wash only. Clean with a
damp cloth and mild soap; do not use solvents, ammonia or
bleach.
Do not use abrasive cleaners or scrubbing pads.
• Follow the lining washing instructions on the labels.
• Dry the textile lining completely before using or storing it.
INSTRUCTIONS
operate the lever (E1) and simultaneously pull them out from
the rear support.
fig. 8
them until they click into place.
fig. 9
attached before use.
REAR WHEELS BRAKE
fig. 10
Always engage the brake during stops.
BLOCKING/UNBLOCKING THE FRONT WHEELS
fig. 11
blocked or unblocked simply by operating the lever (P4) by
the front wheel assemblies.
HANDRAIL
fig. 12
or completely removed; to open it, pull the lever (B1) and
remove it from its housing.
To remove it, repeat the operation on the other side as well.
Warning: never attach the bumper bar in the direction
opposite the one shown.
ADJUSTING THE BACKREST
fig. 13
pressing the button (P5) on the central device (P6).
fig. 14
control device (P6) and simultaneously pull the rear ring (P7).
SAFETY BELTS
fig. 15
remove the shoulder straps (P8) by detaching the velcro that
secures them on the belts (P13), then pull them out of the
loops on the backrest (P9). Use both back straps always at the
same height.
HINTS FOR CLEANING THE TEXTILE LINING
Do not bleach
Do not tumble dry
Dry flat in shade
Do not iron
Do not dry clean
Do not spin-dry
To reinstall them, simply position them and push
Caution: make sure that the wheels are properly
To operate the brake, use the rear central lever (P3).
The stroller features swivelling wheels that can be
The bumper bar (B) can be opened on one side
To lower the backrest, release the rear strap by
To lift the backrest, press the button (P5) on the
If the height of the back straps must be changed,
