Inglesina VESPA Qid2 Bedienungsanleitung Seite 105

Use a screwdriver (or similar tool, not included) to operate the lever (E1) and
simultaneously pull them out from the rear support.
To reinstall them, simply position them and push them until they click into place.
Caution: make sure that the wheels are properly attached before use.
REAR WHEELS BRAKE
To operate the brake, use the rear central lever (P3).
Always engage the brake during stops.
BLOCKING/UNBLOCKING THE FRONT WHEELS
The stroller features swivelling wheels that can be blocked or unblocked simply by
operating the lever (P4) by the front wheel assemblies.
BUMPER BAR
The bumper bar (B) can be opened on one side or completely removed; to open
it, pull the lever (B1) and remove it from its housing.
To remove it, repeat the operation on the other side as well.
Warning: never attach the bumper bar in the direction opposite the one shown.
ADJUSTING THE BACKREST
To lower the backrest, release the rear strap by pressing the button (P5) on the
central device (P6).
To lift the backrest, press the button (P5) on the control device (P6) and
simultaneously pull the rear ring (P7).
SAFETY BELTS
If the height of the back straps must be changed, remove the shoulder straps (P8)
by detaching the velcro that secures them on the belts (P13), then pull them out of the
loops on the backrest (P9). Use both back straps always at the same height.
Once the correct position has been found, re-insert the shoulder straps (P8) on
the back straps, making sure that the velcro (P13) adheres correctly.
Make sure that the back strap is properly inserted in the ends of the waist one
(P10).
Fasten the ends of the waist belt to the central buckle (P11).
Always use the crotch strap (P12) in combination with the waist strap, making
sure that they are all well adjusted around the baby.
Caution! Failure to comply with this precaution can cause the baby to fall or slide
out, with serious injury risks.
Caution: adapt the height and the length of the harness according to the baby's
growth.
HOOD
To adjust the hood, simply accompany it to the desired position.
The hood features a fabric insert that extends the degree of cover, improving
protection from the sun.
HOOD VENTILATION
The back of the hood can be removed and completely folded down to allow for greater air
circulation.
central buckle (A2).
REMOVING THE HOOD
To remove the hood (A
Press the lever (A3) on the central joint (A4) and simultaneously remove the hood
from the housings (A5) on the stroller.
A1) and wrap the hood back, locking it with the small
A1).
