Using in the Rear Facing Mode
(Child height 40cm-105cm/Child weight
19kg/infant - 4 years old)
see images -
20 30
!
Please install the enhanced child
restraint on the rear vehicle seat
and then put the child in the
enhanced child restraint.
1. Press the ISOFIX adjuster button
-1 and pull the base back from
20
the vehicle seat.
2. Press the rotating button to rotate
for easier side loading/unloading
of the child, then rotate the seat
to the rear facing position.
!
Press the rotating button on either
side to rotate the enhanced child
restraint.
17
20
2
1
21
&
21 22
3. After successfully installing the
ISOFIX connectors, press the
ISOFIX adjustment buttons again
while pushing the seat back until
it comes in contact with the
vehicle seat back. -1 -2
23 23
!
The ISOFIX connectors must be
attached and locked onto the
ISOFIX anchor points. -1
24
!
The load leg must be installed
correctly with green indicator.
-2
24
22
23
1
2
24
2
1
18
