Ambient conditions:
Sensor
Degree of protection for the tip acc. to EN 60529
Pressure tightness (expected based on the design):
Sensor tip
Sensor and corrugated tube protection
Driver
Degree of protection for the driver acc. to EN 60529
Dimensions (WxHxD)
Operating temperature
Operating temperature range, sensor and cable
Operating temperature range, driver
b
Storage temperature
Altitude
Polution degree
Humidity
a. When stored or operated at a temperature of less than -30 °C, the protection class is reduced to IP65
b. When stored in original package
8.2

Dimensioning of assembly adapter

Figure 2 Dimensional drawing of assembly adapter
* Predetermined breaking point for separating the mounting tabs for mounting on hat-rails
© Brüel & Kjaer Vibro GmbH
50,5
*
/
2mm ds821/14.9.20/technical specifications subject to change/C105227.001/V02
IP68 / 2 h at 10 bar
25 bar
25 bar (valid only for ds1002)
IP20
26,5 mm x 83 mm x 60 mm
-55 °C ... +180 °C
-55 °C ... +85 °C
-20 °C ... +70 °C
< 2000 m
3 used in the protection of the connections and cable
clamps.
98% non-condensing
with protection of the plug connections and cable clamp
83,0
41,5
25,4
25,4
82,2
30,0
a
