Brüel & Kjær Vibro ds821 Serie Betriebsanleitung Seite 40

2 mm displacement sensor system series ds821|
EN
Instruction
C
AUTION
Danger of injury through moving machine parts. Shut down the plant before
installing the displacement sensor.
C
AUTION
Live components can cause the driver to become defective. Close the electrical
connection and apply voltage only once all parts of the displacement sensor
system have been connected correctly.
N
OTE
The driver housings may not contact each other or any other conductive parts.
Assembly of the sensor:
C
AUTION
The ceramic sensor tip is sensitive to shock. Transport and store the
displacement sensor only with the included protective rubber cap. Always keep
the protective rubber cap for later use.
To avoid damage, make sure, especially during assembly and while operating the
machine, that the sensor tip does not come into
contact with other objects.
Loose ceramic particles can lead to damage within the machine.
Check the tip of the sensor for damage before every assembly. Never install a
defective sensor.
Assembly, disassembly or replacement of components:
N
OTE
Never pull the cable to open the connection. Doing so may damage the cable and
the connector ends.
l
40 © Brüel & Kjaer Vibro GmbH/2 mm ds821/14.9.20/technical specifications subject to change/C105227.001/V02
!
!
!
!
!
Safety
