Usage

4.1 Control panel

To control the parameters, ADX-F-PDP 20-250 dryers are equipped with a controller Comprag
PDP-LOG, which automatically monitors the dew point and optimizes the operation of the
installation.
Fig. 4.1. General view of the Comprag PDP-LOG controller
1. Changing parameters in setting mode
2. Add "+" values
3. Fast forward + press and hold 4sec
Navigates up through the parameters.
Previous parameter
1. Switching the unit on / off
2. Exit the setup mode while saving
the parameters.
Connect the dryer to the electrical network. «Standby» should light up on the screen. When the
button «ON / OFF» is pressed, the dryer will turn on and operate at the previously set values or
the values set by the manufacturer. In this case, the display will show the current parameters:
A drying: 200S -
B regen: 17S -
P.D.P.: -32 °C
Setting parameters
The setting of parameters depends on the environmental conditions and the state of the
incoming compressed air. In standby mode («Standby» is displayed on the screen) press and
hold the «SET»
COMPRAG ADX-F-PDP series
1 3
6 9
Column A: Drying in progress.
Column B: Regeneration in progress. 17 seconds left.
Current dew point value: -32 ° С
button.
2 4
1.
2.
3.
4.
5.
5
6.
7.
8.
9.
7 10 8
10. Start / Stop button
1. Changing parameters in setup mode
2. Add "-" values
3. Fast forward - press and hold 4sec
Navigation down through the parameters.
Next parameter
1. Entering the setting mode
2. Viewing the following pages during
installation
3.Confirming settings, passwords
200 seconds left.
LCD display
Up button
Left button
Right button
Down button
Column indicator A
Work indicator
Column indicator B
Settings
15
