CONNECTION:
LF - CONNECTION CORDS
Choosing high-quality balanced cables( two conductors for the audio signal plus sepearate shielding mesh) with
XLR-type connectors is recommended for LF-signal connection. Although connecting unbalanced cables to the
power amplifier inputs is possible as well, using balanced cables is always preferable. A great number of today s
audio appliances employ balanced outputs. With balanced cabling, the shield connects all metal enclosure parts
and therefore efficiently eliminates the introduction of external interference-mostly noise and hum.
XLR-type connector pin-assignment
X
L
R
(
m
l a
) e
X
L
R
(
e f
m
l a
) e
8
