Installation
4
Installation
4.1
Mechanical connection
Use only original accessories, in case of doubt consult the manufacturer.
Take care that the carrying capacity / working load limit (WLL) of the lifting device/carrier is not exceeded,
through the load of the device, the attaching devices (turning device, fork sleeves etc.) and the additional
load of the gripping goods!
Gripping devices always have to be gimballed, so they can swing freely in any position.
In no case it is allowed to mount gripping devices with lifting devices/carriers in a rigid way!
Break of the suspension may occur within short time. Death, severe injuries and material damage can
result!
The rotator with load is hindered from
swinging freely and hangs diagonally
downwards when the load is lifted.
Risk of breakage!
4.1.1
Standard flange plate
The device is attached to the lifting equipment/carrier with a standard flange plate or a custom made flange
plate connection.
Attaching the device to the lifting equipment/carrier take care that all local safety regulations are observed.
56100050/56100051/56100052/56100053/56100054
The rotator with load can swing freely in any direction and
hangs vertically downwards when the load is lifted.
V1
13 / 20
GB
