General
3.3

Technical data

Typ Opening width
AKZ-UNIGRIP-850
370 – 1.370
56100050
AKZ-UNIGRIP-1000
370 – 1.370
56100051
AKZ-UNIGRIP-1100
370 – 1.370
56100052
AKZ-UNIGRIP-1230
370 – 1.370
56100053
AKZ-UNIGRIP-1300
370 – 1.370
56100054
* The load capacity depends on:
•
Surface condition of the material to be gripped
•
Size of the individual stones
•
parcel size
•
Type of packaging
The load capacities do not apply to stacks of low, unbundled stones, e.g. paving stones!
To ensure a perfect and safe operating state of the device the following setting values have to be
observed:
Setting value
Output of truck loading crane [l/min]
Operating pressure of truck loading crane [bar]
Back pressure [bar]
56100050/56100051/56100052/56100053/56100054
Immersion depth
[mm] [mm]
850
1.000
1.100
1.230
1.300
Load capacity* Pliers body length
(WLL) [kg] [mm]
3.000
2.500
2.500
2.000
1.800
optimal / minimum
25 optimal
180 minimum
0 optimal
V1
Dead weight
[kg]
1.000 310
1.000 320
1.000 325
1.000 345
1.000 350
maximum
75
210
5
12 / 20
