DAC basic/classic
Examples for using the interlock segments
D = 2 -> Runs A and B are being machined
D = 3 -> Runs A, B and A are being machined
4.3
The interlock signal is triggered by an adjustable number of stitches and the reverse trip is completed.
Button Position
3
Single interlock
The forward run is sewn with an adjustable number of stitches. Then the signal for the reverse feed lever is sent
and the reverse run is completed. The number of stitches can be set separately for both runs.
Button Position
3
Doppelriegel
Double interlock
4.4
Button Position
Downloaded from
www.Manualslib.com
Setting the end interlock
Setting
Number
of interlock
stitches
Setting
Number
of interlock
stitches
Setting the multiple end interlock
Setting
manuals search engine
Settings
Settings
Settings
12
User settings
Display
Display
Display
© 2010 Dürkopp Adler AG
