Dürkopp Adler DAC basic Betriebsanleitung Seite 117

DAC basic/classic
12.6
L C
t 12 00 0
t 12 01 0
t 12 02 50
The t
urning back
the
duration of the reverse rotation power on delay ( parameter t 12 02). Then it turns back at positioning speed at
the angle set
by parameter t 12 01.
12.7
The keys are called smart keys which means that the different functionalities can be applied directly to these
keys.
These are programmed using the P key on the OP1000 followed by pressing the corresponding key for about 2
seconds. Confirm the selection by pressing OK.
12.7.1
The
This is programmed using the P key followed by pressing the F key for about 2 seconds. Confirm the selection by
pressing OK.
L C
t 52 20 0
Downloaded from www.Manualslib.com
Turning Back
P Min Max Unit
1 -
180 °
255 ms
function runs after the cutting procedure. When the stop position is reached the drive stops for
Assigning the function keys (smart keys)
Assigning key F on the OP1000
key is called a smart key which means that various functionalities can be applied directly to this key.
P Min Max Unit
13 -
manuals search engine
Description
Turning Back
0 = No;
1 = Yes
Moving angle of rotation
Waiting time up to the turning back
Description
Setting the input function for the OP1000 "F" key
0 = no function;
1 = on threading help;
2 = Bartack suppression/recall;
3 = Manual bartack;
4 = Half stitch;
5 = Full stitch;
6 = Direction finder position;
7 = Turning back
8 = Input function module 1;
9 = Input function module 2;
10 = Input function module 3;
11 = Switch high lift for walking foot;
12 = Ornamental Backtack;
50
Setting the basic functions
