Dürkopp Adler DAC basic Betriebsanleitung Seite 118

12.7.2
The keys are called smart keys which means that the different functionalities can be applied directly to these
keys.
These are programmed using the P key followed by pressing the corresponding key for about 2 seconds. Confirm
the selection by pressing OK.
L C
t 52 20 -
12.8
Thread cutter ON: Press
L C
1 02 01 0
t 02 10 0
t 02 11 0
t 02 20 0
t 02 21 0
© 2010 Dürkopp Adler AG
Downloaded from www.Manualslib.com
Assigning the keypad
P Min Max Unit
0 13 -
25
Thread cutting procedure
. LED on
P Min Max Unit
1 -
359 °
359 °
255 ms
255 ms
manuals search engine
13 = Needle cooling
Description
Setting the input function for the OP1000 "F" key
0 = no function;
1 = on threading help;
2 = Bartack suppression/recall;
3 = Manual bartack;
4 = Half stitch;
5 = Full stitch;
6 = Direction finder position;
7 = Turning back
8 = Input function module 1;
9 = Input function module 2;
10 = Input function module 3;
11 = Switch high lift for walking foot;
12 = Ornamental Backtack;
13 = Needle cooling
Description
Pedal setting to start the cutting process.
0 = Position -2;
1 = Position -1
Power on angle t 08 12 <= t 02 10 < t 02 11
Power off angle t 02 10 <= t 02 11 < t 08 13
Time lag for repeated switching on of the thread cutting magnets.
Time lag for switching off the thread cutter magnets
51
Setting the basic functions
