12.11.2
The lower or upper position of the needle can be set directly using parameter t 08 12 or t 08 13 or by using
parameter t 08 11 in the same way as already described in 4.4.1.
The angle settings always relate to the set reference position.
12.12
L C
t 08 6
t 08 7
t 08 8
t 08 9
This function prevents unwanted wandering of the needle when the machine has stopped.
The effect can be checked by turning the hand wheel.
• Holding force takes effect when idle
- for a stop in the seam
- after the end of the seam
• The effect can be set
• The higher the value set the stronger the holding force
12.13
12.13.1
L C
t 07 00 0
t 07 01 0
© 2010 Dürkopp Adler AG
Downloaded from www.Manualslib.com
Setting other positions
Holding force when idle
P Min Max Unit
0 2 -
0,1 6,00 A
0 255 -
0 999 ms
Setting parameters for backtack and seams
Stitching programming
P Min Max Unit
2 -
1 -
manuals search engine
Description
Motor brake when stopped normally
0 = no brake;
1 = Brake for duration of d0815;
2 = Brake when stopped permanently active
Holding current when machine idle
Responsiveness to changes in the position
Motor brake time period
Description
Treatment position-2 in seam ways.
0 = Demolition of the seam. The next seam way is sewn; The seam is
broken off with thread trimmer at the last seam of the program.
1 = Demolition of the seam with thread performances (even if inactive).
The next seam process is a free seam.
2 = Demolition of the seam with thread performances (even if inactive).
Seam program is stopped.
Automatic system business.
0 = off;
1 = on
