Part no.
70 Bolt, Button Head
71 Bolt, Button Head
72 Bolt, Button Head
73 Bolt, Button Head
74 Bolt, Button Head
75 Bolt, Button Head
76 Bolt, Button Head
77 Stainless Screw, Round Head
78 Screw, Round Head
79 Screw, Round Head
80 Shoulder Bolt, Button Head
81 Lock Washer
82 Washer
83 Washer
84 Washer
85 Washer
86 Acorn Nut
87 Nylon Nut
88 Nylon Nut
89 Nylon Nut
90 Stainless Nylon Nut
91 Large Washer
92 Large Washer
93 Impeller Seal
94 Tank Seal
95 Foam Spacer
96 PC Plate
97 Roller Spacer
98 Idle Roller Short Spacer
99 Stainless Washer
100 Syphon Pump
101 Funnel
102 Knob
103 Knob Bolt
104 Combination Wrench
105 Safety Pin
22
Description Specification
M8 x 50mm
M8 x 30mm
M8 x 15mm
M6 x 45mm
M5 x 35mm
M6 x 15mm
M5 x 10mm
M3 x 20mm
ST4.2 x 16mm
M4 x 12mm
Ø10*6.5*M8*18.5
OD15*ID10.5*T2.5
OD20*ID10.5*T1.5
OD16*ID8.5*T1.5
OD13*ID6.5*T1.5
M3
M10
M10
M8
M6
M3
OD20*ID8.5*T1.5
OD25*ID10.5*T2.0
Ø50*Ø19*5
Ø40*Ø27.4*6.8
Ø98*Ø28*20
OD40*ID20*0.2
Ø8.1 x Ø10 x 13mm
Ø14*1.5*19
OD25*ID20.1*0.3
Ø60*M10
Ø10*119
Q´ty
4
4
10
2
1
16
4
12
4
1
2
2
4
12
2
24
2
3
11
2
12
2
1
1
1
1
1
2
2
1
1
1
1
1
1
1
