Skandika NEMO COMPACT Aufbau- Und Bedienungsanleitung Seite 21

Part no.
31 Strap Pulley
32 Long Idle Roller
33 Cushion pad
34 Seat Roller
35 Lower Seat Roller
36 Moving Wheel
37 Bungee Pulley
38 Spacer for Bungee Pulley
39 Seat
40 Rail Bushing
41 Meter Plate Bushing
42 Stopper
43 Pedal
44 Pedal Strap
45 Handlebar Seat
46 End cap
47 Rectangular Plug
48 Rectangular Plug
49 Hexagon nut
50 Strap
51 Bungee Cord
52 Needle Roller Bearing
53 Hand Grip
54 Computer
55 Sensor Wire
56 Sensor Holder
57 Magnet
58 Grommet
59 Adjustable foot
60 Bearing
61 Bearing
62 Bolt, Flat Socket Head
63 Bolt, Button Head
64 Bolt, Button Head
65 Bolt, Button Head
66 Bearing Spacer
67 Bolt, Button Head
68 Bolt, Button Head
69 Bolt, Button Head
Description Specification
POM
Ø22*6.5*30
Ø51.2*Ø8.5*14.7
Ø12 x Ø8.1 x 6.5mm
PU
Ø16 xØ31.8 x 12.5
Ø25.4*Ø8.2*10
Ø33*Ø8*13
30mm x 70mm
40mm x 100mm
30mm x 60mm
M8
HK2010
Ø6*5mm
Ø12*11*Ø3
6000zz
608zz
M6 x 10mm
M10 x 115mm
M10 x 105mm
M10 x 55mm
OD30*ID26*36
M8 x 135mm
M8 x 110mm
M8 x 70mm
Q´ty
1
1
2
4
2
2
4
8
1
2
2
4
2
2
1
4
2
2
4
1
1
2
2
1
2
1
1
1
4
4
10
2
1
1
1
1
2
2
1
21
