Sharp XR-1X Serviceanleitung Seite 138

XR-1X
Ref. No. Part No.
OPTICAL MECHANISM PARTS
8 Not Available
8-1 CDUC-A052WEF0
8-2 CFiLWA074WJ01
8-3 AN-XR1LP
8-4 GCOVHA057WJSA J Zoom Ring C
8-5 GCOVHA053WJZZ J Color Wheel Cover A
8-6 GCOVHA054WJZZ J Color Wheel Cover B
8-7 GCOVHA055WJSA J Focus Ring C
8-8 GCOVHA051WJSB J Zoom Ring B
8-9 GCOVHA058WJSA J Zoom Ring D
8-10 LCHSKA017WJZZ
8-11 XBBS920P05000
8-12 XBBS925P06000
8-13 DUNTKC435WEF5
8-14 QCNW-C570WJQZ J Thermal Fuse
8-15 XEBS926P06000
8-16 LX-BZA057WJFN
60 QSOCZA073WJZZ
61 PZETZA012WJZZ
62 LHLDZA356WJKZ
63 PSHEGA031WJKZ
64 PRDARA152WJFP
65 MSPRPA038WJFW J DMD HS BIND SP
66 XBPSN30P12JS0
67 XBBSN20P03000
IC9501 RDMDPA012WJZZQ J DMD Chip
6 DUNTKC618WEF0 – Formtter Unit
Downloaded from www.Manualslib.com
★
Description
– Optic Mechanisum Ass'y
J Lamp House Ass'y
J Color Wheel
– Lamp Ass'y, Option article
J Optic Mechanisum Chassis CW
J Screw, x7
J Screw, x2
- Photosensor Unit
J Screw
J Screw, x2
J DMD Socket
J KAPTON INSLT
J Backer Plate
J Thermal Pad
J Heat Sink
J Screw, x4
J Screw, x2
manuals search engine
Code Ref. No. Part No.
—
AR
BT
—
AN
AM
AP
AL
AM
AN
AB
AB
—
AM
AB
AB
BC
AK
AG
AF
AS
AF
AA
AB
EB
—
