1. Description

The EX-44354 is a plug & play high-speed serial RS-232 expansion card for the PCI-
Express bus. The EX-44354 provides four 9 pin high speed RS-232 serial ports. It uses
data transfer rates up to 921Kbaud/s. The EX-44354 design utilizes the FTDI chipset
with 256-byte buffer, which incorporates the latest in high speed interface technology. In
combination with the fast PCI-Express bus it provides a secure and very high data
transfer on each port. It supports all PCI-Express slots x1 to x16. It is not possible to
change the address or IRQ settings manually, they will be obtained automatically by the
system BIOS and operating system. The EX-44354 allows you to provide +5V and
+12V on pin 1 and pin 9 of the serial ports. Please note if you use power to pin 9 your
peripheral device must support it. There is additionally a 8 cm low profile slot bracket for
installation in small computer housing.
Features:
•
PCI-Express x1 to x16
•
300 Baud up to 921.6 KBaud
•
RS-232
•
Windows 200x/ XP/ Vista/ 7/ 8.x/ 10/ Server 20xx/ Linux/ Mac OS
•
Certificate for

2. Extent of Delivery

Before you install the EX-44354 in your PC, you should first check the contents of the
delivery:
•
EX-44354
•
Octopus Cable
•
Low Profile Bracket
•
Driver CD
•
Manual
